Nominal Voltage
|
48V
|
Dimensions
|
482*420*178
|
|
|
Nominal Capacity
|
100Ah
|
Weight
|
48Kg
|
|
|
Capacity@20A
|
300min
|
Terminal Type
|
Connector
|
|
|
Energy
|
4800Wh
|
Case material
|
Steel
|
|
|
Resistance
|
≤30mΩ
|
Enclosure Protection
|
IP20
|
|
|
Efficiency
|
99%
|
Cell Type
|
Prismatic
|
|
|
Self discharge
|
≤3.5% Per month
|
Chemistry
|
Lifepo4
|
|
|
Maximum Module in parallel
|
15
|
Configuration
|
15S1P
|
|
|
Maximum continuous discharging current
|
50A
|
Recommend charge current
|
40A
|
|
|
Peak discharging current
|
150A≤3s
|
Maximum charge current
|
50A
|
|
|
BMS discharge current cut-off
|
130A±20A
|
Recommend charge Voltage
|
52.5-54V
|
|
|
Recommend Low voltage disconnect
|
42V
|
BMS charge voltage cut-off
|
54V(3.75±0.1V)
|
|
|
Discharge Temperature
|
-20 to 60 ℃
|
Certifications
|
CE/UN38.3/IEC
|
|
|
Charge Temperature
|
0 to 45 ℃
|
Communication
|
RS232/RS485/CAN
|
|
|
Low Temperature cut-off charge
|
0 ℃ （Customized）
|
Shipping Classification
|
UN3480,CLASS9
|
|
|
High Temperature cut-off charge
|
54℃（Customized）
|
Warranty
|
5 Years
|
