| Battery Input Data | PV String Input Data | AC Output Data | General Data | ||||
| Battery Type | LiFePo4 | Max.DC Input Power(W) | 10000 | Rated AC Output and UPS Power(W) | 10000 | Operating Temperature Range | -25℃~60℃ |
| Battery Voltage Range | 48V-57.6V | PV Input Voltage(V) | 550(150~800) | Max.AC Output Power(W) | 11000 | Noise(DB) | <45dB |
| Max. Charging Current(A) | 200A | MPPT Range(V) | 200~650 | Peak Power(off grid) | 2 times of rated power(10s) | Communication with BMS | RS485,CAN |
| Max. Discharging Current(A) | 200A | Start-up Voltage(V) | 160 | AC Output Rated Current(A) | 15 | Weight(KG) | 129KG |
| Charging Curve | CC-CV | PV Input Current(A) | 20+10 | Max. Continuous AC Passthrough(A) | 50 | Dimension | 422*254*1482mm |
| Energy | 10.752kWh | No. of MPPT Trackers | 2 | Output Frequency and Voltage | 50/60Hz;230/400V AC(3 phase) | Max. Continuous AC Passthrough(A) | 50/60Hz,230/400V AC(3 phase) |
